Description

Transmission : Drive from the engine is provided with roller chain & sprockets. The drive to loader shaft through hydraulic jack. The machine can be operated by Diesel Engine or Electric Motor.

Power : 8 H.P., 1000 R.P.M., Air Cooled Diesel Engine OR 5 H.P., 415 V 50 Hz 3 Phase, 960 R.P.M. Electric Motor.

Mixing Drum : Heavy duty C.I. Casting with bearings & M.S blades for efficient mixing.

Approx. Dimension : Length 9' 6", Width 6' 8", Height 9' 5", Weight 1350 Kg.

Handling : Pneumatic wheel with roller bearing with excel shaft.
